Reference: MH5320
Genuine
Ricoh GEN6 Printhead MH5320 J352-04/J376-03 cable 447mm Use For M5000
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
Genuine Ricoh GEN6 Printhead MH5320 J352-04/J376-03 cable 447mm Use For M5000
This printhead is made of the two skus J352-04 and J376-0
This Ricoh GEN6 head (MH5320 series) is compatible with UV based inks. The service life of the MH5320/MH5340 is more than double that of the MH5421/MH5441 that preceded it.
A minimized 5pl droplet size and improved jetting accuracy yields excellent print quality without graininess. With 1,280 nozzles configured in 4 x 150dpi rows, this head achieves high-resolution 600dpi printing. Greyscale features a maximum frequency of 50kHz, allowing for increased productivity.
This prinhead is available with a cable (including connector) of either 145mm or 447mm. This printhead has a cable of 447mm and a total length including the printhead of 500mm.
Specifications:
-Dimensions: 89 x 25 x 69 mm (excluding cables)
-Head materials: SST, Nickel alloy and Epoxy Adhesive
-Nozzle plate surface: Coated SST
-Number of nozzles: 4 x 320 nozzles
-Nozzle spacing: 0.1693 mm
-Nozzle density: up to 600 npi
-Temperature control: Integrated Heater and Thermistor
-Operator temperature range: 60° C
-Drop volume: Binary mode : 5pl / Grey-scale mode : 5-15pl
-Jetting frequency: 50kHz (3 levels); 40kHz (4 levels)
-Ink compatibility: UV
This printhead carries 1 year manufacturer warranty and 30 days company warranty.
Country of origin : Japan
Use For:
- M5000
- SG6 2030
- MC2512RV
- Hollanders Colorbooster 320
